Fragment Booster™ Schematic Plus Mods

$2.00
10% off for Plus Members, 5% off for Basic Members. Promotion auto-applied on checkout.

Here are 5 schematics from my Fragment Booster™ Video
It's an awesome-sounding Class A signal Booster that is insanely easy to Build & Modify

Please Note: This schematic comes directly from my "McPherson Schematic Vault." It includes the schematic only—no layout or wiring diagram. For those comfortable with reading schematics, additional diagrams aren’t necessary anyway :)

I won't be able to provide build support, so purchasing this assumes you have experience with reading schematics and assembling circuits independently.
